Technical parameters

Circuit Diagram

Certificates

Insulating material, Flammability rating

PA，V0

Dimensions

Width/Length/Height(mm)

46.2/85/48.8

Maximum electrical data

Imax(A)

220

Umax(V)

800

Electric parameter

Rated voltage(V)

800

Nominal current(A)

220

Connection capacity(mm2)

16-95

Hexagon screw inner size

6＃

Ordering data

Ground Terminal Block

Part No.

Color

Order No.

Pcs/Pkt.

WKL95/2-PE

Yellow/Green

100422004

5

Accessories

Description

Part No.

Color

Order No.

Pcs/Pkt.

Terminal Block

WKL95/2

Grey

100421004

5

WKL95/2 BU

Blue

100421004BU

5

Tool:Hex Wrench

WKT-BS1.5/10

-

104103004

-

Merker Carrter

JKLM3

-

100221004

100

Marker strip

Central marker

ZB8

Blank

100222013

100

ZB8

Standard numbers

100222014

100

ZB8

Customized words

100222015

100
